Small Well Drilling Machine

Product Features

1.Precise lateral drilling; horizontal or inclined drilling can be completed in a shaft or limited space, and underground obstacles (rock layers, sand layers, pipelines, etc.) can be crossed to improve the flexibility of water well or pipeline layout.

2.Hydraulic integrated control; small well drilling machine adopts hydraulic drive propulsion, rotation, and lifting are integrated, and the operating handle is centrally controlled, no additional power output is required, the training cycle is short, and it is easy to get started.

3.Adjustable inclination angle; the drill frame of the small well drilling machine can adjust the drilling angle to meet the needs of downhill, uphill, and oblique oriented drilling, and is suitable for applications such as underground pipe corridors and slope grouting.

4.Compact structure; modular design of the whole machine, can be quickly disassembled and assembled;  it can enter narrow lanes or underground shafts for operation, reducing transfer costs.

Parameter Table For Small Well Drilling Machine

Consulting customized requirements, technical parameters can be deeply optimized to match your actual scenario.

The Applicable Scope Of Small Well Drilling Machine

1. Urban underground: Drilling in the shaft to the water source or underground obstacles and then drilling horizontally to facilitate the laying of water supply and drainage, communication, gas and other pipelines.

2. Underground water well: On the basis of vertical wells, drilling obliquely or horizontally to the surrounding area to increase the water source collection radius and increase water production.

3.Horizontal drilling in mines: Horizontal drilling in mine shafts, used for gas extraction holes or mining support holes, etc.

THe Structural Composition Of Small Well Drilling Machine

1.Power system; The small well drilling machine boasts a powerful 4-kW rotary motor and a 2.2-kW propulsion motor, delivering unmatched efficiency and stability. It effortlessly conquers the toughest geological conditions, ensuring smooth and uninterrupted drilling progress.

2.Hydraulic control system; including hydraulic pump station, control valve group and pipeline; realizes precise adjustment of propulsion, rotation and lifting; hydraulic components are selected from internationally renowned brands with high stability.

3.Appearance material;the small well drilling machine is welded with high-strength alloy steel ; the guide rail has high precision to ensure smooth movement of drill rod.

4.Slewing propulsion walking mechanism; composed of hydraulic slewing head and propulsion cylinder;  large slewing torque, strong propulsion force, suitable for complex formations。

5.Cleaning system；The steam bottle on the small well drilling machine provides a steam-mixed flushing medium to clear debris from the borehole, cool the drill bit, and enhance drilling efficiency, ensuring a smooth drilling process.

Packaging And Transportation

1. Modularized packaging: The whole machine is divided into modules such as power unit, drilling rig mainframe, hydraulic pump group, rotary propulsion component, etc., which are packaged in wooden boxes or steel frame pallets.

2. Protective measures: Anti-vibration and dust-proof treatment of hydraulic components, motors and key pipelines; Anti-rust paint is sprayed on exposed metal parts and wrapped with anti-rust film.

3. Logistics method: Support railway transportation; export customers can choose to put the whole machine into pallets or ship by module in bulk, and provide packing list, packing diagram and operation manual.

4. Delivery cycle: 3-7 working days for conventional models, and 15-30 working days for customized models depending on the configuration.

After-sales Service

1. Warranty policy: The warranty period for the whole machine is 12 months or 1500 operating hours (whichever comes first), and the core hydraulic components and power system enjoy a 1-year warranty.

2. Technical support: 7×24 hours online technical consultation; provide remote video guidance installation and commissioning services.

3. Accessories supply: Common wearing parts (drill bits, drill rods, filter elements, hydraulic oil seals, etc.) are in sufficient stock to ensure fast delivery within 48 hours.

4. Training service: Free Chinese and English operation manuals, maintenance manuals and operation teaching videos; engineers can be dispatched for on-site training according to customer needs (some areas).

FAQ

Q1: Can the small well drilling machine drill horizontally at the bottom of the shaft?

A: Yes, the horizontal drilling rig can achieve horizontal or inclined drilling at the bottom of the shaft or the platform position, and the guide casing can ensure the drilling accuracy.

Q2: What measures can be taken to prolong the service life of drilling equipment?

A:To extend the lifespan of drilling equipment, ensure strict adherence to the operating manual and avoid overloading.  Additionally, schedule routine professional maintenance to keep the equipment clean and minimize corrosion and wear.

Q3: How to control the operating depth and horizontal distance?

A: The extension length of the drill tool is controlled by the hydraulic cylinder stroke and the length of the winch rope on the main machine; the drilling depth and direction can be monitored in real time with an inclinometer or depth sounder.
